Hot AC 220V Digital Speed Controller AC Motor Speed Control Unit 0 100% Adjustable Range 6W to 200W for Choose

Hot AC 220V Digital Speed Controller AC Motor Speed Control Unit 0 100% Adjustable Range 6W to 200W for Choose
  • Продавецthestraightway.info
  • Список ценUS $21.56piece
  • Продажная ценаUS $21.56piece
  • ДоставкаБесплатная доставка
  • Рейтинги3,9 (876)

Oписание продукта

light SHOU TU

Features:
1.Multifunctional, can measure AC/DC voltage, AC/DC current, resistance, capacitance,frequency,temperature,diode,continuity,duty ratio .
2.Data storage,misoperation alarm,USB/Bluetooth interface configuration.
3.Stable performance, high precision,TRMS, large LCD screen.
4.There is buzzing and low battery, overload protection.
5.Data hold, easy to read.

Description:
1.This multitester is used to measure AC/DC voltage, DC/AC current, resistance, capacitance,frequency,temperature,diode,continuity,duty ratio.
2.Auto power off, low power consumption.
3.It\'s a perfect tool for the laboratory, factory and home.

Specification:
Brand:UNI-T
Model: UT171C
Color: Red & Gray
Working environment: 0-40℃
Storage environment: -10-50℃
Monitor: 60000counts
Over range indication: “OL” display
Automatic shutdown: yes
Diode Test: yes
Battery Type:Lithium battery 7.4V/1800mAh
DC voltage range: 600mV/6V/60V/600V/1000V
DC voltage accuracy: ±(0.025%+5)/±(0.03%+5)
AC voltage range: 600mV/6V/60V/600V/1000V
AV voltage accuracy: ±(0.4%+40) -- ±(4%+40)
DC current range: 600μA/6000μA/60mA/600mA/6A/10A
DC current accuracy: ±(0.25%+20) -- ±(0.5%+2)
AC current range: 600μA/6000μA/60mA/600mA/6A/10A
AC current accuracy: ±(0.75%+20) -- ±(1.5%+5)
Resistance range: 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ/60nS
Resistance accuracy: ±(0.05%+10) -- ±(1.0%+10)
Capacitance range: 6nF/60nF-600nF/6mF-60mF
Capacitance accuracy: ±(3%+30)/±(2.5%+5)/±10%
Frequency range:60Hz-10MHz
Frequency accuracy: ±(0.1%+5)
Duty ratio range:1%-99%
Temperature Range: -40~1000℃/-40~1832℉
Current capliper range:60A/600A DC; 60A/600A AC
Aquare-wave output frequency:0.5Hz-4800Hz
Item weight:508g
Item size:205 x 95 x 55mm

Package Information:
Package Size: 294x 185 x 94mm/ 11.57 x 7.28 x 3.7in
Package Weight: 1072g/2.36lb
General Box Package

Package List:
1 x Multimeter
1 x Pair of test leads
1 x Thermocouple
1 x USB Cable
1 x Bluetooth interface
1 x Current calipers
1 x Carry bag
1 x User manual
